QA1 MVFR8 MV Series 3 Piece Bronze Race Rod End 8mm Bore M8X1.25 RH Female Thread

QA1’s MVF Series carbon steel metric female rod ends with bronze race are generally appropriate for low load, high oscillation applications. These commercial rod ends are protective coated for corrosion resistance and are available with right- or left-hand threads. Flush mount grease fitting is included. Stud variations are available.

• BALL: 52100 Bearing Steel, Heat Treated, Precision Ground, Hard Chrome Plated,
• RACE: Sintered Bronze, Oil impregnated
• BODY: Carbon Steel, Protective Coated for Corrosion Resistance

Specifications

• Rod End Series: MV Series
• Style/Construction: 3 Piece Bronze Race
• Bore: 8mm
• Thread Direction: RH
• Thread Size and Pitch: M8X1.25
• Male or Female Thread: Female
• PTFE Lined?: No
• Configuration: Standard
